3D Kinetic LED Screen 160

Series

  Indoor 3D Kinetic LED Display
160

  Outdoor 3D Kinetic LED Display
160

Model

160-I

500-O

Pitch

Indoor-P1.98

Outdoor-P10

LED Module Dimension(WxH)(mm)

160×160

495×245

Gap between Units(mm)

1(0.5～1.5)

5(3.5～6.5)

Motion Unit Dimension(WxH)(mm)

160×160 (0.0256m²)

    495×495 (0.25m²)

Resolution of Unit

80×80

48×48

Cabinet Dimension(Motion Units Qty)

640×480 (4×3)

    1000×1000 (2×2)

Cabinet Thickness（Standby mode）(mm)

320

   1400

Max. Forward Stroke(mm)

200

   600

Max. Forward Speed(mm/s)

300

   800

Min. Forward-back Cycle Time(s)

＜0.7

  ＜1.5

Motion Qty per Sqm

39

  4

Weight per Sqm(Kg/m²)

80

  180

Max. Power Capacity(w/m²)

900

   1500

Power Supply Requirement

≤3KW:220V Single phase

≥3KW:380V Three phases/Five wires

    380V Three phases

  /Five wires

Screen Brightness(cd/m²)

≥700

≥7000

Ambient Temperature(℃)

0～40℃

 -10～60℃

IP Rating

IP40

         IP65

Environmental Attentions

No etchant gas, No inflammable gas, No oiled mist and dust

Heat Dissipation

Open self-cooling (with fan cooling)

Semi-closed Self-cooling  (with fan cooling)
