Egret Series

Name: Egret Series
Brand: SpectrumDisplay
Availability: InStock

Egret Series ultra-thin flat panel display module features an exceptionally slim 20mm profile, creative seamless splicing and stunning visual performance, delivering a premium indoor viewing experience. It supports front magnetic quick installation and maintenance, dual redundancy for stable operation, and common-cathode energy-saving technology. Fully customizable in size, resolution and shape, it is reliable and ideal for a wide range of high-end indoor applications.

Commercial

Egret Series

Features

Magnetic Assembly, Effortless Maintenance

A precision magnetic structure makes installation fast and simple and enables professional, efficient front maintenance. No complex disassembly is required, greatly reducing on-site installation and servicing difficulty and improving project implementation and maintenance efficiency.

Dual Redundancy for Dependable Operation

Display modules support dual power redundancy and dual receiving-card backup. Should a single link fail, automatic switching prevents downtime and blackout, guaranteeing uninterrupted, stable output for high-grade applications.

Common Cathode IC, Precise Power Control

Advanced common-cathode driver ICs enable precise power control that closely matches the photoelectric characteristics of the RGB primary colours. Current distribution is optimised to improve colour performance while reducing power consumption, delivering finely graded and colour-accurate images.

Multi-Dimensional Customisation

Size, resolution and form factor can all be customised and adjusted according to site conditions and application requirements. Curved, right-angle, corner and other splicing shapes are supported, meeting the needs of differentiated projects.

Specification

Series	Egret Series 1000x250 Innovative Tablet Display
Pixel Configuration	3 in 1 SMD
Pixel Pitch (mm)	1.5625	1.953	2.604	2.976
No. of Modules per Unit Case (WxH)	1x4/1x3/1x2
Unit Case Resolution (WxH)	160x640/160x480/160x320	128x384/128x384/128x256	96x384/96x288/96x192	84x336/84x252/84x168
Unit Case Dimensions (WxHxD, mm)	250x1000/250x750/250x500
Unit Case Surface Area (m²)	0.25/0.1875/0.125
Weight per Square Meter (kg/m²)	19.2/16.64/19.2
Physical Pixel Density (pixels/m²)	409600	262144	147456	112896
Flatness of Unit Case (mm)	±0.2
Unit Case Material	Aluminum Profile
Service Access	Front
Max. Brightness	600-800		600-3000
Color Temperature	6500
Visual Viewing Angle (Horizontal)	140
Visual Viewing Angle (Vertical)	120
Brightness Uniformity	0.95
Color Uniformity	±0.015Cx,Cy
Contrast Ratio	4000
Processing Depth (bit)	16
Power Consumption (W/m², Max.)	500
Power Supply (V)	100-240V
Frame Rate (Hz)	50 / 60
Refresh Rate (Hz)	7680
LED Half-Brightness Lifetime	100000 Hours
Operating Temperature (°C)	-20 ℃ to 50 ℃
Operating Humidity	10-80% RH
Protection Level	Indoor IP30, Outdoor IP65
